** 3 Years guarantee **
The portable DIGITTRADE HIGH SECURITY HDD is currently the best solution to save data at a high standard of security and mobility.
Incl. Acronis TrueImage OEM Quick Backup Software
Thanks to the full disk hardware encryption according to the 256 bit AES in CBC mode and the two factor authentication, by smartcard and 8-digit PIN, the DIGITTRADE HIGH SECURITY HDD combines the benefits of mobile data media with highest security standards for data privacy.
The encrypted HDD offers with its features in combination with the HS Smartcard Management System a lot of solutions for single users, companies and public authorities.
Besides, you receive with the Acronis True Image OEM Quick Backup software all necessary extras which you need to the restoration of a computer system in the disaster case. If mistakes appear which block an access to information or influence the operating system, you can simply restore the system and lost data.
1. Encryption
During transfer on the HDD, all data is stored in real-time by a 256 bit full disk encryption according to AES in CBC mode.
The Advanced Encryption Standard (AES) is a symmetrical cryptographic system, approved by USA’s National Security Agency for top secret information.
The CBC mode ensures that for encryption of a block always information of the block encrypted before will be included. This means that in case of same plain text there will never be the same cipher text. It will not be possible to draw conclusions from cipher texts to plain texts.
Additionally to all stored data, even temporary files as well as areas that would normally not be noticed by encryption software will be encrypted.
2. Authentication
The DIGITTRADE HIGH SECURITY HDD works with a
according to the
Factor 1 (Having): verifies, if the user has a smartcard with the correct AES key.
Factor 2 (Knowing): verifies, if the user knows the correct 8-digit PIN and consequently is authorized to use this smartcard.
Only after successful authentication the AES key used for encryption will be transferred to the encryption chip set and the user will have access to the data.
3. Smartcard
Serially the HDD is delivered with the smartcard Atmel CryptoMemory® AT88SC0104C. This offers enough security in everyday life.
For especially high security requirements the smartcard Oberthur Cosmo 64 v5.4 is optionally provided, certified by FIPS 140-2 level 3. These smartcards can be used either exclusively or in combination with the Atmel smartcards.
In case of any manipulation the smartcard will be irrevocably destroyed and disabled.
4. AES Key
The AES key is stored in the smartcard and cannot be read out from enclosure or HDD in case of loss or theft.
The construction of the HDD allows changing the AES keys as often as desired. Fur this purpose the new smartcards must be created with the adequate match key of the enclosure. New data will be saved with the new AES key after the quick formatting of the HDD. The access to old data will be only limited possible by data recovery and using the old AES key.
5. HS Smartcard Management System
The HS Smartcard Management System (HS SMS) is optionally provided. It allows:
- > to generate AES keys
- > to write new AES keys on new smartcards
- > to manage smartcards, AES keys and users
- > to write existing AES keys on a new smartcard
6. Implemented HDD
The implemented 2.5” SATA HDD makes the mobile data safe small and handy. Thanks to data transfer and power supply using USB or FireWire and the hard ware encryption it is possible to use this storage medium independent of an operating system or platform.
G-Force Protection: robust solutions for modern mobility
This Technology prevents the HDD from head crash, the impact of the read-/write head on the data disk, if the HDD falls to the ground or is exposed to hard impacts. A sensor recognizes, if the HDD is in the free fall. Within 0.3 seconds the disk will take the heads off the data disk into parking position and switch off the power.
7. Supported Operating Systems
The HDDs are bootable and are independent of any operating system. This allows the users not only to store files and programs on the HDD, but also programs and complete operating systems.
8. Acronis True Image OEM Quick Backup Software
With the help of the Acronis True Image OEM Quick Backup you can guarantee the security of all information on your computer. It can protect the operating system, installed application, settings and all your data; you can extinguish no longer required confidential data securely. You can protect partitions with this software.
Acronis Online Backup enables to you to store your most important files on a distant storage. Should the system hard disk be damaged or be struck by a virus or malicious software, you can restore the secure data easily and fast.
Features
| Manufacturer of HDD: | Samsung |
| Bus type: | SATA 3.0 Gb/s |
| Capacity: | 500 GB |
| RPM: | 5400 |
| Transfer rate: | 480 MBit/s (USB 2.0), 800 MBit/s (FireWire 800) |
| Average access time: | 12 ms |
| Buffer: | 8192 KB |
| Noise creation: | 23 dBA |
| MTBF: | 600000 hours |
Security features
| 256 bit full disk hardware encryption according to AES in CBC mode |
| 2-factor authentication by smartcard and 8-digit PIN code |
| AES Key stored separately from the HDD and enclosure on smartcard |
| Access protection onto the smartcard with the 8-digit PIN |
| Encryption chip FIPS-197 certified |
| Security solution FIPS-140-2 conform |
| Atmel CryptoMemory AT88SC014C Smartcard |
Special Features
| no restrictions on read and write speed |
| independent from operating system |
| compatible to Windows, Linux and Mac |
| bootable |
| USB 1.1 / 2.0 |
| FireWire 100 / 200 / 400 / 800 (9 pin connection) |
| 3 Years guarantee |
Dimensions
| Product dimensions: | 130mm (L) x 78mm (B) x 22mm (H) |
| Weight: | 250g incl. HDD |
| Tare weight: | 600g |
Acronis True Image OEM Quick Backup:
Backup features:
| Backup of running system (hot backup) |
| Disk/Partition backup |
| Full Backup |
| Incremental Backups |
| Online Backup |
Recovery features:
| Recovery of system partition |
| Recovery of data partition or disk |
| Recovery a disk backup to a different capacity hard disk |
| Recovery files and folders |
| Recovery files and folders from image archives |
1. DIGITTRADE HS256 HIGH SECURITY HDD 500GB, 2 Smartcards Typ Atmel CryptoMemory AT88SC014C, USB-Y-Cable, User Manual, Hard Case
2. Acronis True Image OEM Quick Backup Software: installation file, user manual and licensing agreement in electronic form on the device
